Flame retardant heat shrink tube 2:1 insulation tubing pipe

  • Flame retardant heat shrink tube 2:1 insulation tubing pipe
Name:Flame retardant heat shrink tube 2:1 insulation tubing pipe
Name:Flame retardant heat shrink tube
Shrink ratio:2:1
Feature:Low smoke , Halogen-Free
Flame retardant:Yes
Start Shrink:84℃
Full recovery:120℃
Working Tem:-55℃ to 125℃
Color:Standard black, or colorful
Certifiicate:RoSH, UL-224

Product Description


2:1 Flame Retardant Heat shrink tube size
Specification(mm)
                       Size after shrink (mm)
Max IDWall thickness
Φ0.8≤0.500.33±0.10
Φ1.0≤0.650.33±0.10
Φ1.5≤0.850.33±0.10
Φ2.0≤1.000.36±0.10
Φ2.5≤1.300.36±0.10
Φ3.0≤1.500.45±0.10
Φ3.5≤1.800.45±0.10
Φ4.0≤2.000.45±0.10
Φ4.5≤2.300.56±0.10
Φ5.0≤2.500.56±0.10
Φ5.5≤2.800.56±0.10
Φ6.0≤3.000.56±0.10
Φ7.0≤3.500.56±0.10
Φ8.0≤4.000.56±0.10
Φ9.0≤4.500.56±0.10
Φ10.0≤5.000.56±0.10
Φ11.0≤6.000.56±0.10
Φ12.0≤6.000.56±0.10
Φ13.0≤6.500.56±0.10
Φ14.0≤7.000.70±0.10
Φ15.0≤7.500.70±0.10
Φ16.0≤8.000.70±0.10
Φ17.0≤8.500.70±0.10
Φ18.0≤9.000.70±0.10
Φ20.0≤10.000.83±0.10
Φ22.0≤11.000.83±0.15
Φ25.0≤12.500.90±0.15
Φ28.0≤14.000.90±0.15
Φ30.0≤15.001.00±0.15
Φ35.0≤17.501.00±0.15
Φ40.0≤20.001.00±0.15
Φ45.0≤22.501.00±0.20
Φ50.0≤25.001.00±0.20
