Silicone Fiberglass sleeve tube 1.5kv 4kv 7kv

  • Silicone Fiberglass sleeve tube 1.5kv 4kv 7kv
Name:Silicone Fiberglass sleeve tube 1.5kv 4kv 7kv
Name:Fiberglass Sleeve tube
Temperature Resistant:-60℃~200℃
Flame retardant level:VW-1
Certificate:RoHS, SGS
Feature:Wear resistance,Anti-Corrosion

Product Description

      Product Parameters
Properties
Specification Requirement
Continuous Operation Temperature -60℃~200℃
Cold Bend No cracking
Aging Test No cracking(260℃ and 6hours conidition)
Horizontal Flame Test >30s
Combustion(vw-1)>30s
Volume Resistance10''Ωcm
Tempertaure Endurance 200℃ ±2℃ ,168≥1/2 Original Voltage Solution
Submerge Water Test No changes


Inner Diameter

(mm)

                                                   The wall thickness  ( inner fiberglass & outer silicone)



       Package

1.5kv2.5kv4kv7kv
Φ1.00.250.300.350.40


200m/Roll

Φ1.50.250.350.350.45
Φ2.00.300.350.350.45
Φ2.50.300.350.400.45







100m/Roll

Φ3.00.300.350.400.45
Φ3.50.300.350.400.50
Φ4.00.300.350.400.50
Φ4.50.300.350.400.50
Φ5.00.350.450.450.55
Φ5.50.350.450.450.55
Φ6.00.350.450.450.55
Φ7.00.350.450.500.55
Φ8.00.350.450.500.55










50m/Roll

Φ9.00.350.450.500.55
Φ10.00.400.500.500.55
Φ11.00.400.500.500.60
Φ12.00.400.500.600.60
Φ13.00.400.500.600.60
Φ14.00.400.500.600.60
Φ15.00.400.500.600.60
Φ16.00.400.500.600.65
Φ17.00.450.550.600.65
Φ18.00.450.550.600.65
Φ19.00.450.550.600.65
Φ20.00.500.550.600.70
Φ25.00.550.600.650.75


  25m/Roll

Φ30.00.701.00//
Φ35.00.801.10//
